Specification
| Input | 90 ~ 264 V AC 2A 47 … 63 Hz |
| Output | 13.6 V, 8 A |
| Battery charge | 13.8 V, 3 A |
| Rated power | 108 W |
| Efficiency | main power: 82%
by battery power: 94% |
| Charging method | constant current / constant voltage (CC/CV) |
| Protection | from short circuit;
output overload; reverse-polarity; from deep battery discharge. from running on a discharged battery. |
| Battery cutoff voltage | 10.8 V |
| Start by battery | at voltage > 12.0 V |
| Battery type | Lead-acid 12 V (VRLA - AGM/GEL) |
| Recommended battery capacity | 12 … 100 Ah |
| Working temperature | 0 … +60 °C (+32 … +140 °F) |
| Working humidity | up to 90%, non-condensing |
| Dimentions | 222×115×40 mm (8.74×4.53×1.57″) |
| Weight | 550 g (19.40 oz) |
